Breadth-First Search (BFS)

BFS explores a graph layer by layer from the start node, guaranteeing the shortest path in unweighted graphs. It employs a queue to track frontier nodes.

Typical uses include maze-solving, peer-to-peer broadcast, and determining the minimum moves in puzzles such as the 15-tile game.

Complexities — Time: O(V + E)  |  Space: O(V)

Pseudocode

function BFS(start, goal):
  queue ← new Queue()
  queue.enqueue(start)
  visited ← {start}
  parent ← map()

  while not queue.isEmpty():
    node ← queue.dequeue()
    if node == goal:
      return reconstructPath(parent, start, goal)
    for neighbor in node.neighbors():
      if neighbor not in visited:
        visited.add(neighbor)
        parent[neighbor] ← node
        queue.enqueue(neighbor)
  return []

Depth-First Search (DFS)

DFS dives deep along branches before backtracking, using recursion or an explicit stack. It excels at exploring tree-like structures and detecting cycles.

Applications: generating mazes, topological sorting, and identifying connected components in images or graphs.

Complexities — Time: O(V + E)  |  Space: O(V) (max recursion)

Pseudocode

function DFS(start, goal):
  stack ← new Stack()
  stack.push(start)
  visited ← {start}
  parent ← map()

  while not stack.isEmpty():
    node ← stack.pop()
    if node == goal:
      return reconstructPath(parent, start, goal)
    for neighbor in node.neighbors():
      if neighbor not in visited:
        visited.add(neighbor)
        parent[neighbor] ← node
        stack.push(neighbor)
  return []

Dijkstra’s Algorithm

Dijkstra computes shortest paths in graphs with non-negative edge weights by expanding the node with the smallest tentative distance stored in a min-heap.

Used in GPS navigation and network routing (e.g., OSPF) where accurate distance metrics are critical.

Complexities — Time: O((V + E) log V)  |  Space: O(V)

Pseudocode

function Dijkstra(start, goal):
  dist   ← map(default = ∞)
  dist[start] ← 0
  parent ← map()
  pq     ← new MinHeap()
  pq.insert((0, start))

  while not pq.isEmpty():
    (d, node) ← pq.extractMin()
    if node == goal: break
    for (neighbor, w) in node.neighbors():
      alt ← d + w
      if alt < dist[neighbor]:
        dist[neighbor] ← alt
        parent[neighbor] ← node
        pq.insert((alt, neighbor))
  return reconstructPath(parent, start, goal)

A* Search Algorithm

A* augments Dijkstra with a heuristic function h(n) estimating remaining cost to the goal, dramatically reducing explored nodes while preserving optimality if the heuristic is admissible.

Standard in game AI and robotics path planning; choose Manhattan or Euclidean heuristics for grid worlds, or domain-specific estimates for complex maps.

Complexities — Time: depends on heuristic (≤ Dijkstra)  |  Space: O(V)

Pseudocode

function A*(start, goal, h):
  g ← map(default = ∞)
  g[start] ← 0
  f ← map(default = ∞)
  f[start] ← h(start)

  parent ← map()
  open   ← new MinHeap()
  open.insert((f[start], start))

  while not open.isEmpty():
    (fScore, node) ← open.extractMin()
    if node == goal:
      return reconstructPath(parent, start, goal)
    for (neighbor, w) in node.neighbors():
      tentative ← g[node] + w
      if tentative < g[neighbor]:
        g[neighbor] ← tentative
        f[neighbor] ← tentative + h(neighbor)
        parent[neighbor] ← node
        open.insert((f[neighbor], neighbor))
  return []

Bubble Sort

Repeatedly swaps adjacent out-of-order elements, letting the largest “bubble” to the end each pass. Simple but slow (quadratic time).

Good for teaching purposes or nearly-sorted lists where early-exit optimization makes it almost linear.

Complexities — Time: O(n²)  |  Space: O(1)

Pseudocode

function bubbleSort(A):
  n ← length(A)
  for i in 0 to n-2:
    swapped ← false
    for j in 0 to n-2-i:
      if A[j] > A[j+1]:
        swap(A[j], A[j+1])
        swapped ← true
    if not swapped: break

Selection Sort

Finds the smallest element in the unsorted region and swaps it to the front. Performs n passes regardless of initial order.

Makes only O(n) swaps, so it can be preferable when write-operations are expensive (e.g., EEPROM memory).

Complexities — Time: O(n²)  |  Space: O(1)

Pseudocode

function selectionSort(A):
  n ← length(A)
  for i in 0 to n-2:
    minIndex ← i
    for j in i+1 to n-1:
      if A[j] < A[minIndex]:
        minIndex ← j
    swap(A[i], A[minIndex])

Insertion Sort

Builds the final sorted list one element at a time by inserting each new element into the correct position among already-sorted elements.

Fast (O(n)) on nearly-sorted data; used inside hybrid sorts (e.g., TimSort) for small sub-arrays.

Complexities — Time: O(n²) worst / O(n) best  |  Space: O(1)

Pseudocode

function insertionSort(A):
  for i in 1 to length(A)-1:
    key ← A[i]
    j   ← i-1
    while j ≥ 0 and A[j] > key:
      A[j+1] ← A[j]
      j ← j-1
    A[j+1] ← key

Merge Sort

Divide-and-conquer: recursively splits the list, sorts each half, then merges sorted halves. It’s stable and guarantees O(n log n).

Excellent for external sorting of huge files and is the backbone of language library implementations (Java, Python’s TimSort variant).

Complexities — Time: O(n log n)  |  Space: O(n)

Pseudocode

function mergeSort(A):
  if length(A) ≤ 1: return A
  mid   ← floor(length(A)/2)
  left  ← mergeSort(A[0..mid-1])
  right ← mergeSort(A[mid..])
  return merge(left, right)

function merge(L, R):
  result ← []
  while L and R not empty:
    if L[0] ≤ R[0]:
      result.append(L.popFront())
    else:
      result.append(R.popFront())
  return result + L + R

Quick Sort

Picks a pivot, partitions elements into < pivot, = pivot, > pivot, then recursively sorts partitions. Average O(n log n) time and in-place (O(log n) extra space).

The most widely used general-purpose in-memory sort (e.g., C stdlib), but worst-case O(n²) if pivots are chosen poorly.

Complexities — Avg Time: O(n log n) / Worst: O(n²)  |  Space: O(log n)

Pseudocode

function quickSort(A):
  if length(A) ≤ 1: return A
  pivot ← choosePivot(A)
  L ← [x in A if x < pivot]
  E ← [x in A if x == pivot]
  G ← [x in A if x > pivot]
  return quickSort(L) + E + quickSort(G)

Greedy Assignment

Iteratively picks the locally best pair (highest score), removes them from the pool, and repeats until empty. Fast (typically O(n²)) but may miss the global optimum.

Use cases: quick matching heuristics when speed is critical and optimality is negotiable.

Pseudocode

function greedyMatch(leaders, followers):
  matches ← []
  while leaders and followers not empty:
    (bestL, bestF, bestScore) ← argmaxScorePair(leaders, followers)
    matches.append((bestL, bestF))
    remove bestL from leaders
    remove bestF from followers
  return matches

Monte Carlo Search

Generates many random assignments, scores each, and retains the best. Quality improves with more iterations but runtime grows linearly.

Use cases: approximating solutions when evaluation is cheap but the search space is enormous.

Pseudocode

function monteCarloMatch(leaders, followers, iterations):
  best ← null
  bestScore ← -∞
  for i in 1..iterations:
    perm ← randomShuffle(followers)
    score ← evaluate(leaders, perm)
    if score > bestScore:
      bestScore ← score
      best ← zip(leaders, perm)
  return best

Simulated Annealing

Starts with a random solution, applies random swaps, and occasionally accepts worse moves with probability exp(-Δ/T). Temperature T gradually cools, reducing uphill moves over time.

Use cases: escaping local optima in complex search spaces (e.g., job-shop scheduling).

Pseudocode

function simulatedAnnealingMatch(initial, T0, α, iterations):
  current ← initial
  best ← current
  bestScore ← evaluate(current)
  T ← T0
  for i in 1..iterations:
    next ← randomSwap(current)
    Δ ← evaluate(next) - evaluate(current)
    if Δ > 0 or random() < exp(-Δ / T):
      current ← next
    if evaluate(current) > bestScore:
      best ← current
      bestScore ← evaluate(current)
    T ← T * α
  return best

Genetic Algorithm

Maintains a population of candidate solutions, selects parents by fitness, produces offspring via crossover and mutation, and iterates across generations.

Use cases: optimizing combinatorial problems (e.g., traveling salesman, feature selection).

Pseudocode

function geneticMatch(leaders, followers, popSize, generations):
  population ← initPopulation(leaders, followers, popSize)
  for g in 1..generations:
    fitness ← [evaluate(ind) for ind in population]
    matingPool ← selection(population, fitness)
    offspring ← crossoverAndMutate(matingPool)
    population ← offspring
  return argmax(population, evaluate)

Tabu Search

Explores the neighborhood of the current solution while maintaining a short-term memory (tabu list) of recent moves to prevent cycling.

Use cases: vehicle routing, graph coloring, and other optimization problems requiring strategic exploration.

Pseudocode

function tabuMatch(initial, tabuLimit, iterations):
  current ← initial
  best ← current
  tabu ← Queue()
  for k in 1..iterations:
    neighborhood ← generateNeighbors(current)
    candidate ← argmax(neighborhood \\ tabu, evaluate)
    move ← diff(current, candidate)
    tabu.enqueue(move)
    if tabu.size() > tabuLimit: tabu.dequeue()
    current ← candidate
    if evaluate(current) > evaluate(best):
      best ← current
  return best
